Upgrade your LED lighting system with the SP630E , designed to support both PWM and SPI addressable LED strips. This versatile controller works with popular IC chips such as WS2811, WS2812B, WS2813, WS2815, SK6812, LB1934, and more. With Bluetooth connectivity and the Banlan X App, you can create stunning lighting effects, synchronize lights with music, and customize colors with ease.

Perfect for RGB, RGBW, and RGBCCT LED strips, this controller is ideal for home décor, gaming setups, ambient lighting, and DIY projects. Whether you're looking for static colors, dynamic effects, or sound-reactive lighting, the SP630E delivers an immersive experience.

Key Features:

Dual Compatibility: Works with both PWM (non-addressable) and SPI (addressable) LED strips.
Bluetooth App Control: Use the Banlan X App to control lighting effects, brightness, and color customization.
Music Sync Mode: Built-in microphone lets the lights react to music, enhancing your party or gaming experience.
DIY Custom Effects: Personalize and program your own lighting patterns.
Color Calibration: Adjust colors to ensure accuracy with LED strip output.
Multiple Timer Settings: Set up to 5 timers to automate your lighting.
Memory Function: Retains previous settings even after power loss.
Wide Voltage Support: Compatible with DC 5V, 12V, and 24V power sources.

Specifications:

• Model: SP630E
• Connectivity: Bluetooth
• Supported LED Types: PWM (non-IC) & SPI (IC addressable) LED strips
• Compatible IC Chips: WS2811, WS2812B, WS2813, WS2814, WS2815, SK6812, LB1934, etc.
• Supported LED Strip Types:
  • PWM (Non-IC): 5050, 2835, 3528, 5630, 5730
  • SPI (IC-based): RGB, RGBW, RGBCCT addressable LED strips
• Power Input: DC 5V, 12V, or 24V (via 5.5mm x 2.1mm DC jack)
• Max Current: 6A per channel, 12A max
• Control Method: Banlan X App
• Lighting Modes: Static, dynamic, music-reactive, DIY custom effects
• Music Sync: Yes (via phone microphone, player streaming, or built-in mic)
• Timer Function: Yes (up to 5 timers)
• Memory Function: Yes (saves settings after power loss)
• Dimensions: Compact & lightweight design

Package Includes:

• 1x SP630E Bluetooth LED Controller
• 1x User Manual

Note:

• Power supply not included – please use the correct voltage (5V/12V/24V) based on your LED strip requirements.
• Only compatible with SPI (single data wire) LED strips – not compatible with SK9822, WS2801 (Data + Clock LED strips).

Upgrade your lighting with the SP630E Bluetooth LED Controller today! Perfect for home ambiance, gaming, parties, DIY projects, and more!

Attention

1. Please turn off the power supply before installation.
2. Please ensure input voltage to be same as requirements from device.
3. Don’t disassemble the device if you are not an expert, otherwise it will damage it.
4. Please do not use the light in the place with wide range metal area or strong electromagnetic wave nearby, otherwise, the remote distance will be seriously affected.
